AUTO
Manual Control
LIVE INSTRUMENTS
| Tag | Value |
|---|---|
| PT-01 (In) | 2.22 bar |
| FM-01 (In) | 261.09 m³/h |
| FCV-01 (In) | OPEN |
| PT-02 (Out) | 1.68 bar |
| FM-02 (Out) | 138.10 m³/h |
| FCV-02 (Out) | OPEN |
61.2 %
FROM
SOURCE
SOURCE
PRESSURE
TRANSMITTER
TRANSMITTER
FLOW METER
FLOW CONTROL
VALVE
VALVE
2.22 bar
261.09 m³/h
TOTALIZER
352.35 m³
OPEN
TO
DISTRIBUTION
NETWORK
DISTRIBUTION
NETWORK
PRESSURE
TRANSMITTER
TRANSMITTER
FLOW METER
FM-02
FLOW CONTROL
VALVE
VALVE
FCV-02
1.68 bar
OUTLET FLOW
138.10 m³/h
TOTALIZER
1179.36 m³
OUTLET VALVE
OPEN
DRAIN VALVE
CLOSED
Live Trends
Tank Level (%)
Flow Rates (m³/h)
Pressure (bar)
Net Flow (m³/h)
Active Alarms
1
HIGH
1
MEDIUM
1
LOW
0
ACKNOWLEDGED
| ID | Time | Tag | Description | Value | Priority | Status | Action |
|---|---|---|---|---|---|---|---|
| ALM-001 | 12:28:10 | TL-001 | Tank level above 80% high threshold | 61.2% | HIGH | ACTIVE | |
| ALM-002 | 12:15:42 | PT-01 | Inlet pressure deviation from setpoint | 2.22 bar | MEDIUM | ACTIVE | |
| ALM-003 | 11:50:05 | FM-02 | Outlet flow rate below setpoint | 138.1 m³/h | LOW | ACTIVE |
Reports
Daily Report
24 Jun 2026
Inlet: 352.35 m³
Outlet: 1179.36 m³
Weekly Report
Jun 17 – Jun 24, 2026
7-day avg level: 58.4%
Monthly Report
June 2026
Total inflow: 8,420 m³
Live Data Snapshot
| Parameter | Tag | Value | Unit | Status |
|---|---|---|---|---|
| Tank Level | TL-001 | 3.06 | m | NORMAL |
| Tank Volume | TV-001 | 613.20 | m³ | NORMAL |
| Inlet Pressure | PT-01 | 2.22 | bar | NORMAL |
| Inlet Flow | FM-01 | 261.09 | m³/h | NORMAL |
| Outlet Pressure | PT-02 | 1.68 | bar | NORMAL |
| Outlet Flow | FM-02 | 138.10 | m³/h | NORMAL |
| Net Flow | NF-001 | 122.99 | m³/h | NORMAL |
System Events
| Time | Type | Tag | Event | Value | User |
|---|---|---|---|---|---|
| 12:30:45 | INFO | SYS | System status checked | Normal | System |
| 12:28:10 | ALARM | TL-001 | Tank level high alarm triggered | 61.2% | System |
| 12:10:00 | CTRL | FCV-01 | Inlet valve opened | OPEN | admin |
| 11:55:00 | CTRL | FCV-02 | Outlet valve opened | OPEN | admin |
| 11:30:00 | SYSTEM | SYS | System startup complete | — | System |
